Description
SmallRig Swivel Adjustable Monitor Mount 3601B locks into place via a NATO clamp at one end and attaches to a monitor via a unique SmallRig quick release plate at the other end. The quick release plate is reserved for 2 optional dowel pins, which can be removed and installed as needed to effectively prevent the devices from deflection. It swivels 360° and tilts 150°, and thus stops at any angle. 3601B has a dynamic load capacity of 1.5kg and its damping of pivot is adjustable through the spanner. Comes with silicone pads on the top to prevent scratches and increase friction.
Designer: Tracy Joy
Compatibility:
SmallHD Focus Series, Focus OLED Series, UltraBright Series, 500 Series, 700 Series; Atomos Ninja Series, Shogun Series; Blackmagic Video Assist 5”, Blackmagic Video Assist 4K 7”, Odyssey7Q+, Odyssey7Q, etc.
Note:
1.In order to prevent accidental contact from causing unlocking, the structure of HawkLock Quick Release is designed to prevent accidental contact, and the wrench also has a certain free movement in the locked state. The situation mentioned above is not a quality problem without affecting normal use.
2.The dowel pins are only compatible with Atomos Ninja V, Ninja V +, Atomos Shinobi 7; The dowel pins need to be removed when using other brands of monitors.
Package Includes:
1 x QR Monitor Mount
3 x Allen Wrench
Product Dimensions: 52.5x 46 x 36mm
Package Dimensions: 76X63X40mm
Net Weight: 121g±5g
Package Weight: 166g±5g
Material: Aluminum Alloy, Stainless Steel
*Please note the import duty may occur, and it should be on buyer’s side.
